Name: Perlite Expansion Technology and Processing Plant
Brand: Zhengzhou Hengyang Industrial Co., Ltd
SKU: perlite
Price: 562,000.00 USD
Availability: InStock

Home > Products > Mineral Processing Plant >

Perlite Expansion Technology and Processing Plant

perlite expansion processing plant

mineral processing plant technology

perlite expansion plant equipment

Place of Origin:

China

Brand Name:

hengyang

Certification:

ISO9001

Model Number:

perlite

Document:

Perlite Mining Process Mach...ry.pdf

Request A Quote

Perlite Expansion Technology and Processing Plant

Product Details

Application:

Perlite

Capacity:

1.2-20t/h

Color:

Customize

OEM:

Provided

Installation:

30 Days

Training:

5 Days

Payment & Shipping Terms

Minimum Order Quantity

Price

335000-789000

Packaging Details

negociated

Delivery Time

30-50 days

Payment Terms

T/T

Supply Ability

20 sets/month

Perlite Expansion Rotary Kiln Plant

Get Best Price

Perlite Expansion Technology and Processing Plant

Get Best Price

Rock Phosphate Washing Process

Get Best Price

Limestone Beneficiation

Get Best Price

86-371-56611369

Contact Now

Product Description

When expanded at high temperature, perlite is transformed into a lightweight, porous industrial product with strong insulation properties. It is widely used in the construction, agriculture, filtration, textile and industrial sectors. Quality production requires the correct process, precise temperature control and robust automation.

Henan Dajia designs and builds turnkey perlite expansion plants tailored to the investor's site conditions, fuel type, capacity requirements and target product range.

What is Perlite?

Perlite is a naturally occurring mineral of volcanic origin that contains chemically bound water. When heated to high temperatures, it expands and its volume increases many times over. The resulting product is lightweight, thermally insulating and low-density. For these reasons, expanded perlite is preferred as a lightweight plaster aggregate, insulation material, horticultural soil conditioner and filtration aid.

Main Technical Performance Index Please See The Following Table:

No	Item	No	Item	No	Item
1	Perlite Sand Storage Tank	8	Cooling Water Tank	15	Finished Products Tank
2	Belt Conveyor	9	Furnace Interface Seal Device	16	Top Dust Collector
3	Bucket Lifter	10	Preheating Furnace Interface With Screw Separator	17	Preheating Interface Dust Collector
4	Crushing and Screening	11	Screw Separator	18	PLC System
5	Preheating Furnace Support	12	Multi-Tube Dust Collector	19	Air Compressor
6	Preheating Perlite Sand Transit Tank	13	Pulse Jet Bag Filter Dust Collector
7	Expansion Furnace	14	Recycle Device

Production Process

1. Crushing & Screening: Raw perlite from the quarry is reduced to the appropriate particle size.
2. Drying: Moisture content is reduced to prepare the ideal raw material for expansion.
3. Storage: The prepared material is held in silos or hoppers under controlled conditions.
4. Rocket Feeder: Raw perlite is fed precisely into the expansion furnace via a frequency-controlled system.
5. Expansion: Rapid expansion is achieved at high temperature, yielding lightweight and porous perlite.
6. Packaging or Transfer: The product can be bagged or transferred to the next unit in the line.
