Name: Coconut Fiber Rotary Dryer
Brand: Zhengzhou Hengyang Industrial Co., Ltd
SKU: FILBER DRYER
Price: 562,000.00 USD
Availability: InStock

Home > Products > Rotary Drying Machine >

Coconut Fiber Rotary Dryer

Coconut fiber rotary dryer machine

Rotary drying machine with warranty

Industrial coconut fiber dryer

Place of Origin:

China

Brand Name:

hengyang

Certification:

ISO9001

Model Number:

FILBER DRYER

Document:

Rotary Dryer catalogue.pdf

Request A Quote

Product Details

Capacity:

1.5-13t/h

Condition:

New

OEM:

Voltage:

Upo To Client

Application:

Coconut Fiber Drying

Material:

Q235, SS304,SS316

Warranty:

24 Months

Payment & Shipping Terms

Minimum Order Quantity

Price

335000-789000

Packaging Details

negociated

Delivery Time

30-50 days

Payment Terms

T/T

Supply Ability

20 sets/month

Black Soil Rotary Drying Machine

Get Best Price

double cone rotary vacuum dryer

Get Best Price

Contact Now

Product Description

Palm fibers drying machines are mainly constituted of heat source , heat exchangers, feeding machine , rotary drum , discharging machine , circulating fan, residue cleaning systems , and power distribution cabinets. With the stirring of lifting flights, silk fibers in the drum are uniformly contacted with hot air. With fast heat and mass transfer, the dried silk fiber is discharged in the outlet. The process parameters of production line and the equipment selection and design are the result of careful analysis of the silk fiber material and verified though the actual test. Our engineers fully take into the factors of flammability, clumping and the wrapped bran residue. We adopt a series of unique original technology and processes to address the above problems, making sure the cleanliness and drying effect of silk fibers.

Coconut Fiber Rotary Dryer 0

Model(HY)	1409	1615	2008/3	2010/3	2210/3	2510/3	2512/3	2912/3
Input Capacity(t/h)	1.53	2.89	5.20	6.63	7.24	8.91	10.50	12.14
Output Capacity(t/h)	1.08	2.03	3.67	4.68	5.11	6.29	7.41	8.57
Vaporization(t/h)	0.45	0.85	1.53	1.95	2.13	2.62	3.09	3.57
Early Moisture(%)	40±5%
Final Moisture(%)	15%(adjustable)
Drying Temperature(°C)	280±30℃
Total Power(KW)	34	45	78	90	105	125	140	155
Total Weight(T)	22	28	40	45	50	60	68	76
Plant Area(M)	5*15	6*22	8*16	8*18	8*20	10*20	10*24	10*24
Note: the marked price is only part of the stand-alone machine price, the complete production line machine pric

Main Features

1) Specific design and manufacture for silk fiber materials. Unique structure, low energy consumption and high thermal efficiency
2) Safe heat exchanging mode. The dried silk fibers keep same color, strength and flexibility
3) Frequency conversion control & automatic temperature control. Flexible set of operating parameters based on the required drying
effect
4) Unique residue cleaning system. The wrapped residue in silk fiber is cleaned in the drying process
5) Modular design and manufacture, solid structure, easy installation , low maintenance costs and long service life
6) As a whole production line, the dryer can be used together with palm fiber extraction machine, and screening machine Coconut Fiber Rotary Dryer 1
